Dalian Feida Heavy Machine Tool Manufacture Co.,Ltd manufacture this series CNC single column vertical lathe machine adopts advanced technology ,advanced CAD design method,good static and dynamic rigidity to sure of operation safety,long service and good efficiency.This machine can carry out the following operations on the materials of ferrous metal,nonferrous metal and part non-metal int.and ext.Cylinder turning,taping,curving,or inch and kinds of complex swiveling curve can be carried out on the machine.

Technical specification of CK5123

Max.turning diameter (mm) 2300

Table diameter (mm) 2000

Max.working height of workpiece (mm) (1)Working height of standard model:1350mm

(2)Working height of increasing 250mm:1600mm

(3)Working height of increasing 450mm:1800mm

Max.weight of workpiece (t) 8

Speed -step of table: Four gears Stepless

Max.travel of crossbeam (mm)  1000/1250/1450

Travel of railhead Horizontal(mm) -20--1150

Travel of railhead Vertical(mm) 1000/1250/1450

Power of main motor(kw) 37

Speed range of table (r/min) 2.5--100

Weight of machine(About t)  17.5

Overall dimensions(LxWxH)  (1)Standard model 3210x2850x3300

(2)Increasing 250mm 3210x2850x3550

(3)Increasing 450mm 3210x2850x3750

More CNC vertical lathe model and detailed parameters please see website
